Electrocoating

This is the generic term for electrochemical painting systems for the automated coating of various goods.

Anodic dip painting (ATL):
The object is connected as an anode (positive pole).

Cathodic dip painting (KTL):
The workpiece to be processed forms the cathode (negative pole) here.

All electrophoretic coatings (suspensions of binders and pigments in fully demineralized water with only low concentrations of organic solvents) are water-soluble. Ionization of binders such as resins is necessary. The binders with low water solubility are organic polymer compounds with embedded functional groups.

In anodic dip coating, a proton is separated/neutralized from the carboxylic acid group by means of an alkali (OH¯ group).

Cathodic dip coating: Tertiary amines are ionized by the addition of protons.

Paint deposition on the workpiece is triggered by an electric current flow in the suspension and the resulting water electrolysis. The ions thus generated on the workpiece surface cause a reversal of the neutralization reaction; the previously soluble paint binders coagulate and deposit on the workpiece.
