Aluminum handle V2

Alu Griffeleiste V2 – Wiotec Oberflächentechnik - Profile und Griffleisten erhalten Sie in verschiedenen Längen ab Lager in den Oberflächen glanzverchromt, edelstahlfarbig eloxiert und naturfarben eloxiert

The ready-to-mount aluminum handle strips fit ideally into your modern furnishing environment. The aluminum handle strips are particularly suitable for modern kitchens but also for contemporary furniture construction. The aluminum handle strips are made to measure and convince with their restrained design. Aluminum is due to its durability, timeless and in addition to the handleless front, the handle strip represents an additional design element. We can supply you with untreated aluminum handle strips or also in stainless steel look, gold-plated, chrome-plated, anodized and much more.

The aluminum handle strips are available in various dimensions and designs. On request, larger quantities are also possible without any problems. For questions and suggestions we are at your disposal.

Maximum profile length*

6.000 mm (cutting to length on request)


AlMgSi0,5 F22

*) Due to the manufacturing process, there may be slight deviations from the maximum length of 6,000 mm.

Available surfaces**

Copper ***

up to 2 meters

Brass ***

up to 1 meters

Nickel ***

up to 6 meters


up to 6 meters

up to 1 meters

up to 6 meters

on chromium VI and III basis

up to 2 meters

on chrome III basis



up to 6 meters

on request


Other colors

up to 6 meters

on request

**) Other surfaces on request. Due to production conditions, it is possible that there is no surface coating on the contact surfaces at the ends of the profiles (up to 80 mm).

***) These surfaces must be protected from tarnishing by clear varnish if necessary.

Available dimensions

Stacks Image 1035
(a * b in mm)
37 x 145
37 x 195
37 x 245
37 x 295
37 x 368
37 x 395
37 x 445
37 x 495
37 x 545
37 x 595
37 x 757
37 x 795
37 x 895
37 x 995
37 x 1.195
