Plasma CVD
This makes it possible to produce coatings that are only a few micrometers thick. This is done by plasma chemical reactions (chemical vapor deposition) starting from liquid vapors or from vaporizable solids. These layers can consist, for example, of the elements Ti, Al, C, N, O, either individually or in combination. Combination with some plasma diffusion and plasma heat treatment processes can also be realized.
The process improves corrosion protection and prevents premature wear. It is particularly important for aircraft construction, toolmaking and vehicle manufacturing; it is also frequently used in mechanical engineering - wherever steel components are needed that have to withstand even the greatest stresses.
A typical parameter window:
Pressure: 0.1 to 500 Pa
Temperature: 100 to 600 degrees Celsius
Treatment time: in minutes to hours
Plasma excitation: Pulsed direct current (Khz), alternating current in medium frequency (Khz), high frequency (Mhz) or by microwaves (GHz).
This might also interest you ...
Other popular topics that are often clicked on include information on plastic finishing, metal finishing, chrome plating, galvanising, laser engraving or even tin plating:
Any questions? We’ll gladly assist you ...
Any questions?
We’ll gladly assist you ...
WIOTEC® Ense GmbH & Co. KG
Auf den Geeren 9-11
59469 Ense-Höingen, Germany
WIOTEC® Arnsberg GmbH & Co. KG
Wagenbergstraße 55
59759 Arnsberg, Germany
Phone
+49 2938 97833-0
Fax
+49 2938 97833-20
E-Mail
mailwiotec
From metal to precious metal
The company WIOTEC® is your specialist for surface finishing and metalworking. In our electroplating shop, which is managed according to the latest environmental standards, we are capable of finishing both small parts and long parts of up to six meters. This makes us one of the leading and most efficient decorative surface coaters in Europe.
Our most important resource is our employees - with their commitment, competence and experience. Together with them, we work out and develop individual and tailor-made solutions for our customers. From detailed consultation and planning to purchasing, mechanical and chemical pre-treatment, professional electroplating and supplementary services - WIOTEC®'s range of services leaves nothing to be desired.
© 2023 - WIOTEC® - ALL RIGHTS RESERVED.
© 2023 - WIOTEC® - ALL RIGHTS RESERVED.
Brochures, data sheets, etc.
